The Complete Guide to Installing and Configuring OpenClaw (2026)

From 2-minute quick setup to production-grade automation workflows.

Last Updated: February 10, 2026

1. Quick Start (The 2-Minute Installation)
2. Advanced Configuration Deep Dive
3. Automating Installation for CI/CD
4. Security Hardening Guide
5. Integration: Sending Your First Command
6. Advanced Troubleshooting

Most developers treat browser extensions as simple "install and forget" tools. But when you're using OpenClaw for serious browser automation or testing, the extension becomes critical infrastructure. A standard installation is fine for a quick test, but it won't cut it for a secured production environment or a CI/CD pipeline.

AI-driven workflows are transforming how developers build and ship software. In our step-by-step tutorial on building an AI developer workflow with Claude Code and GLM-5 , you’ll learn how to automate coding tasks, improve efficiency, and create a scalable AI-powered development pipeline.

This guide covers the full spectrum. We'll start with the basic manual setup for those who just want to get running, then move immediately into the advanced configurations that power users need.

If you're looking to reduce AI coding costs while maintaining powerful development workflows, check out our complete guide on how to use GLM with Claude Code . This step-by-step tutorial shows how developers can integrate GLM models into Claude Code to boost productivity, improve automation, and build faster with an affordable AI coding setup.

1. Quick Start (The 2-Minute Installation)

If you just need to get the extension running on your local machine for testing, stick to this section. It works for Chrome, Brave, Edge, and all Chromium browsers.

1 Download & Extract

Download the latest release ZIP. Extract it to a permanent location like C:\Tools\OpenClaw\. Do not run it from your Downloads folder.

2 Enable Developer Mode

Go to your extensions page (chrome://extensions), toggle Developer mode ON in the top-right corner.

3 Load Unpacked

Click Load unpacked, browse to your extracted folder, and select it. The extension card should appear.

That's the basics. Now let's get into the real engineering.

2. Advanced Configuration Deep Dive

Connecting to localhost:3000 is easy. Connecting to a secured, remote relay behind a corporate firewall requires a bit more finesse.

Authenticating with Secured Relays

If your relay is exposed publicly (or even on a shared internal network), you should be protecting it with an Authentication Token. Here is how to configure the extension to pass that token.

Open the extension settings.
In the Auth Token field, paste your API key.
This adds an Authorization: Bearer [YOUR_KEY] header to the initial WebSocket handshake.

Config Tip: You can also pass custom headers if your infrastructure requires it (e.g., for bypassing a WAF or identifying the bot traffic).

// Example Header Configuration in Relay
{
  "relay_url": "wss://relay.production.com",
  "headers": {
    "X-Bot-ID": "scraper-01",
    "X-Custom-Auth": "secret-bypass-token"
  }
}

3. Automating Installation for CI/CD

Manually clicking "Load Unpacked" doesn't work when you're spinning up headless browsers in a GitHub Action or a Docker container. You need to load the extension programmatically.

Loading via Puppeteer / Playwright

Pass the --load-extension flag to your browser instance. Note that you also need --disable-extensions-except to ensure no other noise interferes with your tests.

Puppeteer Example

const puppeteer = require('puppeteer');

(async () => {
  const extensionPath = '/app/extensions/openclaw'; // Absolute path is safer

  const browser = await puppeteer.launch({
    headless: false, // Extensions don't work in 'new' headless mode for some versions
    args: [
      `--disable-extensions-except=${extensionPath}`,
      `--load-extension=${extensionPath}`,
      '--no-sandbox'
    ]
  });

  const page = await browser.newPage();
  await page.goto('https://example.com');
  // OpenClaw is now active and connected
})();

Docker Persistency

If running in Docker, map the extension volume so you don't have to re-download it every build.

# docker-compose.yml
services:
  browser:
    image: node:20
    volumes:
      - ./extensions/openclaw:/app/extensions/openclaw

4. Security Hardening Guide

Critical Warning: Never expose your OpenClaw relay port (default 3000) directly to the public internet without protection. It allows remote execution of browser commands.

Method A: SSH Tunnels (Recommended for Dev)

Instead of opening port 3000 on your router, verify the connection using an SSH tunnel. This keeps the traffic encrypted and the port closed to the world.

# Forward local port 3000 to remote server's localhost:3000
ssh -L 3000:localhost:3000 user@your-server.com

Now configure your local extension to connect to localhost:3000, even though the relay is remote.

Method B: API Gateway / Reverse Proxy

If you must expose it (e.g., for a team), put it behind Nginx with Basic Auth or IP whitelisting.

# Nginx Snippet
location /ws {
    proxy_pass http://localhost:3000;
    proxy_http_version 1.1;
    proxy_set_header Upgrade $http_upgrade;
    proxy_set_header Connection "Upgrade";
    allow 192.168.1.0/24; # Allow only internal IP range
    deny all;
}

5. Integration: Sending Your First Command

You're installed. You're secured. Now let's use it.

OpenClaw exposes a REST API on the relay that forwards commands to the browser via the WebSocket connection we just set up.

The "Hello World" of Browser Automation

Open your browser (with the extension running) and a terminal side-by-side. Run this:

# 1. Check valid connection
curl http://localhost:3000/v1/browser/active
# Response: {"id": "chrome-001", "status": "idle"}

# 2. Navigate the browser
curl -X POST http://localhost:3000/v1/browser/navigate \
  -H "Content-Type: application/json" \
  -d '{"url": "https://news.ycombinator.com"}'

If your browser immediately redirects to Hacker News, congratulations. You have a working, remote-controlled browser node.

6. Advanced Troubleshooting

"WebSocket Connection Closed: 1006"

This generic error usually means a network-level block.

Check CORS: If your relay is on a different domain, ensure your relay config allows the origin chrome-extension://[ID].
Check Proxies: Corporate proxies often drop WebSocket connections. Try connecting via a mobile hotspot to rule this out.

"Extension ID Changes on Reload"

When loading unpacked extensions, Chrome may regenerate the ID if the `key` field is missing from `manifest.json`. To fix this for CI/CD consistency:

Pack the extension once manually (`chrome://extensions` > Pack extension).
This generates a `.pem` private key file.
Include this `.pem` file when loading the extension in future builds to keep the ID static.
